[NOS] Pigtronix Gamma Drive

[NOS] Pigtronix Gamma Drive

Sale Sale
$188.00
$188.00 - $188.00
$188.00
$150.40
$150.40 - $150.40
$150.40

VROOM, VROOM.

Gamma Drive is a germanium-enhanced overdrive with active Treble and Bass EQ controls. Achieving articulate, touch-sensitive performance characteristics via a unique mixture of germanium, LED and silicon diodes arranged to produce asymmetrical clipping, Gamma Drive offers overdrive rich in 2nd order harmonics, which creates sweet, blooming tone. Offering a range of overdrive from sparkling clean boost to a raging distortion, Gamma Drive was designed for versatile playing across a wide variety of musical genres.

KNOB-BY-KNOB

Gain: Sets the amount of distortion

Volume: Sets the output level

Treble: Boosts or cuts high frequencies centered at 2kHz

Bass: Boosts or cuts low frequencies centered at 80Hz.

MODEL GAMMA DRIVE
MODEL NAME
 Gamma Drive
SKU
 GDR
FUNCTION
 Overdrive with 2-band EQ
CATEGORY 1
 Overdrive
CATEGORY 2
 Distortion
EXPRESSION
 -
BYPASS
 True Bypass

ELECTRONICS
VOLTAGE
 9VDC
CURRENT DRAW
 100mA
INPUT IMPEDANCE
 10M
OUTPUT IMPEDANCE
 150ohms

BODY
LENGTH (IN)
 1.5
WIDTH (IN)
 3.75
HEIGHT (IN)
 1.75
WEIGHT (LBS)
 0.5
